Mitsubishi XD600U – DLP XGA (1024 x 768) 4500 ANSI


SKU: 179 Category:


With its high brightness, superior colour reproduction, advanced connectivity, power saving features and super long lamp life, the XD600U from Mitsubishi Electric is the perfect blend of performance and cost efficiency.

For excellent performance in the boardroom or classroom, it’s hard to go past the XD600U projector. With excellent brightness and colour quality, the XD600U delivers fantastic XGA images from any video or data source. Features include:

Excellent Brightness and Contrast – Thanks to its high 4500 lumens brightness and 2000:1 contrast ratio, the XD600U always delivers clear, vibrant images even in well lit rooms.

Superb Colour Reproduction – A combination of BrilliantColor™ technology, Color Enhancer™ and a five-segment colour wheel means image colour is reproduced with the utmost accuracy.

Long Lamp Life up to 5,000 hours – The XD600U is capable of running for up to 5,000 hours (in low mode), greatly lowering the cost of ownership.

Quiet 29dB(A)* Operating Volume – For presentations free of distraction from the projector.

High Powered Zoom Lens  – With its specially calibrated zoom lens, the XD600U is capable of projecting a 1.5m diagonal image from as little as 1.7 metres away.

Network Connectivity – The built-in RJ-45 Ethernet connection provides users with remote control and management of the projector over a dedicated LAN system. The supplied ProjectorView Global+ software allows for the simultaneous control of multiple Mitsubishi projectors on the same network.

Visual PA system – Using the supplied projector control software, network administrators can send messages in real-time to multiple Mitsubishi projectors connected to the LAN. Ideal for broadcasting important information in schools or businesses.

Built-in 10W speaker with “Audio Mix” feature – A high-volume 10W speaker is built in to the projector, eliminating the need for an external speaker in a classroom environment. The “Audio Mix” allows the user to adjust the volume of two separate audio outputs (e.g a wireless microphone and DVD player) independently, for greater audio control during presentations.

Low Standby Power use – In keeping with Mitsubishi Electric’s global green policies the XD600U uses less than 1W in standby mode (3W when connected to a network), for better energy efficiency that saves you money while making the projector more environmentally friendly.

Wide range of video and data inputs, including HDMI – Connect multiple devices to the projector at the same time – perfect for fixed installation units.

Filter free design – No filter to clean means less projector downtime for maintenance.

Top Loading Lamp – For easy lamp replacement when the projector is suspended from the ceiling, as the projector does not need to be removed from its mount.

Instant Shutdown – For quick pack up time when moving the projector between location.

3D Ready – Using specialised electronic shutter glasses and 3D Video content, the XD600U can deliver all the impact and allure that comes with a 3D experience

Product Specs

Display technology 0.7″ 1-chip DMD, 12 deg. LVDS, DDP2230
Resolution 1024 x 768 (total 786,432 pixels)
Colour Wheel 5seg. Color Wheel (R/G/B/W/Y)
Brightness (Maximum) 4500 ANSI lumens
Contrast 2000:1
Zoom/Focus Manual Focus & Zoom Lens(Zoom Ratio 1.5:1) ,with Zoom Triger
Projection Lens f=20.6 ~30.1 mm, F=2.4-2.8,  (2.9-4.3m@100″)
Off set axis 7.9:-1 , Hd=0.23m up @100″
Picture Size 40″ ~ 300″ (100″=3.3m)
Source lamp* 280W / 3,000 hours (Normal mode)
230W / 5,000 hours (Low mode)
Computer compatibility 640 x 480(Expand)  – 1024 x 768(Real) – 1280 x 1024 (Compressed), Sync on green available
Video compatibility NTSC/ NTSC 4.43/ PAL (including PAL-M, N) / SECAM/ PAL-60, Component Video: 480i/p (525i/p), 576i/p (625i/p), 720p (750p), 1080i (1125i 60Hz), 1080i(1125i 50Hz), (1080i(1250, 50Hz) is not available)
PC input terminals RGB:mini D-sub 15 pin x 2, HDMI x 1; Audio: Stereo mini jack x 2 (3.5mm)
Video input terminals Composite RCA x 1, S-Video x 1; Audio: Stereo RCA x 1
Output terminals RGB: mini D-sub 15 x 1; Audio: Stereo mini jack x 1 (3.5mm)
Communication terminals RS-232C: 8pin x 1, LAN (RJ-45) x 1
Audio Speaker 10W Mono
Power consumption 390W, less than 1W in Power Standby mode (3W with network connection)
Power Supply AC100 ~ 240 V ±10%, 50/60 Hz
Fan noise 29 dB(A) (Lamp low mode)
Dimensions (W x H x D) 345 x 129 x 270mm (excluding all protrusions)
Weight 3.6 kg
Optional lamp VLT-XD600LP
Included accessories AC Power Cable, VGA (D-sub) Cable, Remote Control (with battery), Quick Start Card, User Manual, Safety Manual, Lens Cap, Lamp Replacement Tool, Soft Carry Case
