Description
AMD200 200W Mixer Amplifier 8 Mic/Line Inputs + 4 Stereo Source Inputs
200W Mixer Amplifier
USB/RS485 Control with DSP
Specifications
Output Power per Channel | 200W | Frequency Response | 60Hz – 20kHz |
Output Mode | 4 Ohm-70V-100V | THD+N | < 0.5% (-2db) |
Input Channels | 6 MIC or Line – Bluetooth – MP3 and Aux | Signal to Noise Ratio | > 92dB |
Input Voltage | 230Vac 50-60Hz or 24Vdc | Input Sensitivity | 0dBu |
Mounting | 1RU | Cooling | Fan-assisted |
Warranty | 5 years |
Product Dimensions (W x D x H) | 430mm x 330mm x 44mm | Shipping Dimensions (W x D x H) | 515mm x 448mm x 112mm |
Net Weight | 7.0 Kg | Shipping Weight | 9.4 Kg |
GTIN EAN | 9323383010116 |
Features
• 200W mixer amplifier
• 8 mic/line inputs + 4 Stereo source inputs
• DSP processing on board with Parametric EQ, compressor, delay and high and low pass filters
• Stereo line output + Mono amplifier output (Constant voltage or Low impedance operation)
• Third party control via serial, Software GUI or via Icon-CP control panel
• 60 Hz – 20 kHz frequency response amplifier output (20 Hz – 20 kHz Line level output)
• Remote VCA master volume control
• Low power contact closure
• Mic/Line inputs have 34 volt phantom power
• 1 RU rack mountable chassis
